Product details
| Odour trap | 50 mm |
| Flow rate | 10,8 l/min |
- To capture the dripping condensation
Application
- Possibility to connect up to three sources of condensation
- Holder for condensation tubes with no direct connection to the trap – dripping is visible
- Combined odour trap with a ball
- Connection to waste pipe Ø32 mm
- Material: polypropylene
Specifications
-
Norms
EN 274
| Quantity (package) | 60 pcs |
| Quantity (pallet) | 960 pcs |
| Dimensions (piece) | 130×100×125 mm |
| Dimensions (package) | 590×390×430 mm |
| Weight (piece) | 0,1619 kg |
| Weight (package) | 9,714 kg |
| Weight (pallet) | 175,424 kg |
- Waste and trap body with a combined odour trap
- Tubing holder
- Plastic rosette
Scope of supply
| S0006-ND | Rosette DN40 |
| S0321-ND | Rosette DN32 |
| S0915-ND | Ball |
| S0942-ND | Flap of condensation trap |
| S0955-ND | Rosette DN32 |
| S1586-ND | Holder |
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| AKS5 | 8595580531683 |  |
