Product details
| Height adjustment range | 310 – 405 mm |
| Functional requirements class I | |
| Acoustic group II | <30 dB |
| Working range | 0,05 – 0,8 MPa |
| Recommended operating pressure | 0,5 – 0,8 MPa |
- For ceramic flushing cistern
- For replacement
Application
- Metal thread length 39 mm
- Built-in filter to trap dirt
- Smooth closing without any shocks
- Adjustable water level
- Low sensitivity to the changing pressure in the water main
- The design allows optimum height adjustment of the valve according to the height of the cistern
- START/STOP flushing mechanism (flushing is terminated by pressing the button again)
- STOP button to adjust the amount of discharged water
- Option of the setting the button off the axis of the valve
- START/STOP chrome button
Specifications
-
Norms
EN 14124, EN 14055
| Quantity (package) | 20 pcs |
| Quantity (pallet) | 320 pcs |
| Dimensions (piece) | 400×200×110 mm |
| Dimensions (package) | 590×430×390 mm |
| Weight (piece) | 0,7778 kg |
| Weight (package) | 15,556 kg |
| Weight (pallet) | 268,896 kg |
- Inlet fill valve A18-1/2”
- Flush valve A2000
- Seal kit
- Fixation set: screw M8×65 – 2 pcs
Scope of supply
| N0006-ND | Nut M36 |
| N0016-ND | Nut G1/2" white |
| N0039-ND | Nut G1/2" white |
| N0088-ND | Conical sealing 36×20.5×4 |
| N0113-ND | O-ring 6,9×1,8 |
| N0125-ND | Strainer for inlet fill valve universal |
| V0001-ND | Flush valve body |
| V0009-ND | Waste outlet for flush valve |
| V0010-ND | Waste outlet nut TR 60×3 |
| V0013-ND | Pin 25 |
| V0016-ND | Conical ring for flush valve |
| V0019-ND | Flush button key 1/2" |
| V0020 M6X80 B-ND | Screw complete |
| V0032-ND | Pin 15 |
| V0037-ND | Stirrup |
| V0038-ND | Push-in spring 63×6,5/8,87×20×9,5 |
| V0056-ND | Sealing 115×70×15 |
| V0072-ND | Universal frame II. |
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| SA2000SK 1/2" CHROM | 8594045936247 |  |
