Product details
- For drainage of large industrial facilities, and other commercial facilities inside buildings, eg. in the chemical and food industries
- For drainage of lower flow rate of water for sanitation, dividing barrier between the dry and wet area
Application
- Industrial slotted drain made of stainless steel (heat treated by pickling and passivation), this process guarantees that the stainless steel even after several years keeps its properties and reliable operation
- Strong anchoring in concrete with simply adjustable legs and side anchors
- The width of the inlet slot is 20 mm
- Adjustable height in the range of 85–125 mm
- Used sealing ensures a completely watertight joint
- Easy and simple installation
- Industrial drain length 1 m
- Drain body material: stainless steel 1.5 mm, DIN 1.4404
Specifications
-
Norms
EN 1253-1
| Quantity (package) | 1 pc |
| Quantity (pallet) | - pc |
| Dimensions (piece) | 1000×110×85 mm |
| Weight (piece) | 3,8721 kg |
| Weight (package) | 3,8721 kg |
| Weight (pallet) | - kg |
- Industrial slotted drain
- Adjustable feet 4 pcs
- Sealings 1 pc
Scope of supply
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| APR7-0221-20 | 8595580573645 |  |
