Drainage channel 100 mm adjustable + Grid for embedding tiles, galvanized steel
ADZ104V-1000
Product details
| Load class K3 | 300 kg |
- For drainage of balconies and terraces
- For permeable areas in the garden
- For drainage around the building facades
- To protect buildings against the ingress of water
Application
- Simple installation
- Easy access to the drain – easy to clean
- Height adjustable drainage channel body 60–80 mm
- Simple connection thanks to the accessories
- Fixing bolts – ensure perfect attachment of the grid in the channel and eliminate the sound effect during the use of the channel
- Galvanized steel grid width 75 mm
- Material of drainage channel: galvanized steel
- Magnetic switch for service setting and cleaning
- Width of the inlet slot 8 mm
Specifications
| Quantity (package) | 1 pc |
| Quantity (pallet) | 80 pcs |
| Dimensions (piece) | 1000×93×70 mm |
| Weight (piece) | 4,1476 kg |
| Weight (pallet) | 331,808 kg |
- Drainage channel adjustable
- Spacer 2 pcs
Scope of supply
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| ADZ104V-1000 | 8595580581206 |  |
